What are the common tools in painting equipment?

What are the common tools used in Powder coating equipment?

Brush and paint tools

1, brush (brush, wool brush, paibi)

(1): for the brush bristle brush made of uniform thickness, length of neat, flexible.

Mainly used for high viscosity, slow evaporation of paint.

Applicable model: 1-4 inches.

(2): wool brush, brush bristles of uniform thickness, length of neat, varnished after similar brush shape.

Mainly suitable for low viscosity, volatile fast coating.

Applicable models: 65mm, 75mm, 100mm

2. Paint roller: it is made of plastic roller made of artificial wool and galvanized or chrome plated metal roller support. It is suitable for large area hand painting and can be operated for a long distance.

Two 、 spraying tools

1 、 air spraying commonly used spray gun has:

(1) the gravity gun (top gun, it uses the pot) gravity, the paint from the top of the pot from the nozzle to the following, and then by means of air to be atomized, suitable for small area repair, low pressure spray.

Spraying requirements: 1.8mm diameter, spray coating, primer

Diameter 1.4mm sprayed finish

(2) suction gun (gun, gun nozzle hole angle), its principle is to use the high speed airflow to spray local decompression, resulting in attraction, the paint from the tank to the suction nozzle to spray, spray, mainly for large area spraying, paint spray benefit is better, can achieve the film thickness and gloss requirements.

(3) the pressure delivery type spray gun, which does not have a paint cup, can be supplied to the spray gun by the pressure, and the working principle is the same as that of the suction type; because of the quality of the hand held spray gun without the paint cup, the spray is convenient for the upper, the lower, the left and the right sides.
